規格

 Performance

 Image Sensor

 640×480 CMOS

 Illumination

 White LED

 Symbologies

 2D

 PDF417, Micro PDF 417, QR Code, Data Matrix, Micro QR Code Aztec, Data Matrix

 1D

 Code-11, Code-128, Code-39, GS1-128(UCC/EAN-128), AIM-128, ISBT-128, Codabar, Code 93, UPC-A, UPC-E, Coupon, GS1 Composite, EAN-8, EAN-13, ISBN/ISSN, Interleaved 2 of 5, Febraban, Matrix 2 of 5, Industrial 25, ITF-6, ITF-14, Standard 25, China Post 25, MSI-Plessey, Plessey, GS1 Databar(RSS)

 OCR

 Passport OCR

 Resolution

 >=3mil

 Typical Depth of Field

 EAN-13

 50mm-260mm (13mil)

 QR Code

 30mm-170mm (15mil)

 Code 39

 50mm-115mm (5mil)

 PDF 417

 50mm-120mm (6.67mil)

 Data Matrix

 35mm-125mm (10mil)

 Scan Angle

 Pitch

 ±60°

 Roll

 360°

 Skew

 ±60°

 Min. Symbol Contrast

 '0.2

 Field of View

 Horizontal 45°, Vertical 34°

 Aiming

 Red LED (625nm)

 Wireless

 Communication Modes

 Synchronous mode, automatic batch mode and manual batch mode

 Radio Technology

 Bluetooth 5.0

 Communication Distance(direct line of sight in open air)

 With Bluetooth

 50m

 Battery

 2200 mAh lithium-ion battery

 Expected Charge Time

 5.5 hours

 Expected Battery Life

 12 hours of continuous operation (scan once per 6 seconds)

 Memory Capacity

 >=15000 pieces Code 128 (20 byte of each Code 128)

 Physical

 Dimensions (L×W×H)

 145×101×68mm

 Weight

 167g

 Charge Voltage

 5VDC±5%

 Interfaces

 USB

 Notification

 Beep, LED indicator, vibration

 Environmental

 Operating Temperature

 -20°C to 60°C (-4°F to 140°F)

 Storage Temperature

 -40°C to 70°C (-40°F to 158°F)

 Humidity

 5% ~ 95% (non-condensing)

 ESD

 ±15 KV (air discharge); ±8 KV (direct discharge)

 Drop

 1.5m

 Sealing

 IP42

 Charge Temperature

 0°C to 45°C (32°F to 113°F)

 Certifications

 Certifications

 FCC Part15 Class B, CE EMC Class B, RoHS, IEC62471, BIS, BQB
